Platforms


    Print
Single Axis Tilting Platform
ST-100-150
Price : 20240.00
Prices are exclusive of taxes and other charges.

Precision Tilting for Diverse Applications

The Holmarc ST-100-150 Single Axis Tilt Platform is designed to provide precise angular positioning for various scientific and industrial applications. With a robust leadscrew drive and a wide tilting range, this platform ensures accurate and stable adjustments. The anodized aluminium construction enhances durability, making it a reliable choice for demanding environments.

Detailed Specifications

    Model No. : ST-100-150

    Platform Size : 150 mm x 100 mm

    Height : 56 mm

    Tilting Range : 0 to 60 degrees, providing a wide range of angular adjustment

    Load Capacity : Capable of supporting up to 3 Kg

    Drive : Leadscrew with link plate mechanism for precise and stable tilt adjustments

    Mounting Options :

     o    Top Mounting : M6 tapped holes on a 25 mm grid for secure attachment of equipment

     o    Base Mounting : M6 CBR slots for breadboard installation

    Material : Made from high-quality anodized aluminium for durability and resistance to wear

Accessories

    Heavy Duty Post : Ensures robust and stable support for the platform

    Heavy Duty Post Base : Provides a firm foundation for mounting the tilt platform (#sold separately)
