Raman / PL Spectroscopy


    Print
Compact Raman Spectrometer
Model : CRS225
Engineered for advanced material analysis
Sample positioning mechanism with auto-alignment
Prices are exclusive of taxes and other charges.

The Compact Raman Spectrometer is a high-performance, compact, and portable spectroscopic instrument designed for precise Raman spectral measurements. Engineered for advanced material analysis, it offers high spectral resolution, a stable CW laser source and efficient optical detection. The system is suitable for scientific research, industrial quality control, and defense applications, ensuring accurate and reliable spectral analysis of various materials.

This spectrometer features an integrated sample positioning mechanism with auto-alignment using a 532 nm laser diode/white light source to ensure accurate sample placement before Raman spectral capture. With a robust design and data interface, it is ideal for precision lab applications and field-based material identification.

Sample Holder and Positioning System

        Auto-Positioning Mechanism :     532 nm Laser Diode based
        Sample Positioning Accuracy :     ±10 µm in front of the optical port
        Positioning Mechanism :     Stepper motor controlled 25 mm travel stage
        Resolution :     1 Micron

Sample Holder Control Mechanism

        Sample Holder Shape :     Open-top circular truncated cone
        Top & Bottom Diameter :     50 & 37 mm
        Height :     12 mm
        Material :     Aluminum
        Sample Holder Movement :     X / Y : ± 20 mm (0.1 mm step)
        Z : ± 25 mm (1 µm step)
        Control Mechanism :     Feedback-based movement using 532 nm Laser Diode spectral peak
