Beam Samplers

AR coating for 400 - 700 nm
Available in different diameters of different thickness

Beam Samplers are used to pick off the sample of a light beam by using the Fresnel reflection from uncoated surfaces. Beam samplers are used for monitoring applications where disturbance of the transmitted beam must be kept minimum. The back surface is wedged to avoid internal fringes and is anti-reflection coated to remove ghost images. Custom Sizes and anti-reflection coatings are available on special request.



    Material :     BK7 or equivalent & Fused Silica
    Surface quality :     40 - 20 ( scratch-dig )
    Dimensional Tolerance :     +0.00, -0.2 nm
    Thickness :     ± 0.2 mm
    Clear aperture :     90 %
    Surface flatness :     λ / 4 @ 632.8 nm
    Reflectance, Ravg :     5% @ 45°
    Wedge :     30 ± 10 arc min
    Coating :     Front surface :- uncoated
    Back surface :- anti-reflection @ 400 - 700nm










Plate Beamsplitters

Plate beamsplitters find applications in splitting or re-combining a light beam. The front surface of our beamsplitter is coated with metallic...



Metallic Cube Beamsplitters

Holmarc's Metallic cube beamsplitters consists of two right angle prisms cemented together. The hypotenuse of the one prism has a combination of metallic-dielectric....



Variable Beamsplitters

Our Circular Variable Beamsplitters (Mounted ) find applications in splitting an incident beam into a transmitted and a reflected beam.



Model No. Diameter ( mm ) Thickness ( mm ) Material Price ($)
HO-BS-N-12.5 12.5 3 BK7 or equivalent 26.00
HO-BS-F-12.5 12.5 3 Fused Silica 38.00
HO-BS-N-25 25 5 BK7 or equivalent 44.00
HO-BS-F-25 25 5 Fused Silica 76.00
HO-BS-N-50 50 8 BK7 or equivalent 73.00
HO-BS-F-50 50 8 Fused Silica 170.00
