Plano Aluminium Mirrors

Coating : Protected Aluminum
Circular & square mirrors are available as standard models

Aluminium Mirrors offer high reflection throughout ultraviolet, visible and NIR region. The mirror coating consists of an Aluminium layer and a very thin protective coating. Custom sizes and flatness are available other than standard models.



    Material :     Borofloat ( schott )
    Thickness Tolerance :     ± 0.2 mm
    Dimensional Tolerance :     +0.00, -0.2 nm
    Clear aperture :     90 % of diameter
    Surface quality :     40 - 20 ( scratch-dig )
    Surface flatness :     λ / 4 @ 632.8 nm
    Parallelism :     ≤ 3 arc sec
    Coating :     Protected aluminium
    Reflectivity Ravg :     > 88% @ 450nm-2μm,
    > 93% @2μm - 20μm
    Damage threshold :     < 200 mJ / cm2 ( @ 532 nm CW laser )
    Bevel :     0.2 mm x 45°




Model No. Size ( mm ) Thickness ( mm ) Price ($)
HO-PCMA-10 ø 10 4 15.83
HO-PSMA-10 10 x 10 4 15.83
HO-PCMA-12.5 ø 12.5 6 19.17
HO-PSMA-12.5 12.5 x 12.5 6 19.17
HO-PCMA-25 ø 25 6 29.17
HO-PSMA-25 25 x 25 6 29.17
HO-PCMA-50 ø 50 6 50.83
HO-PSMA-50 50 x 50 6 50.83
HO-PCMA-75 ø 75 10 144.17
HO-PCMA-100 ø 100 10 279.17



Plano Aluminium Mirror 25

Model No. HO - PSMA - 25
$ 25.59
